Terminal Blocks 1-pol
| 1440836 | 1440838 | |||||
| mm2 | Solid conductors | Rigid conductors | mm2 | Solid conductors | Rigid conductors | |
| 1,5 | 2 | 2 | 2,5 | 2 | 2 | |
| 1,0 | 2 ÷ 3 | 2 ÷ 3 | 1,5 | 2 ÷ 3 | 2 ÷ 3 | |
| 0,75 | 2 ÷ 4 | 2 ÷ 4 | 1,0 | 2 ÷ 4 | 2 ÷ 3 |
Material Terminal housing:
Polykarbonat transparent UL94-V0
Material insert:
Brass
Material Screws:
Galvanized steel
Temperature range:
up to +85°C
Standards:
EN 60998-1:2004, EN 60335-1:2006
Colour:
Transparent
Halogen-Free:
Yes
