- Standard
- Cenelec HD 21,1, HD 22.1
- Approvals
- CE
- Rated Voltage Uo/U
- 300/300V
- Conductor class
- Class 5 = fine stranded wires
- Conductor material
- Copper
- Core insulation
- Silicone
- Core identification
- Blue and Brown
- Outer sheath
- Heat resistant PVC
- Sheat colour
- White
- Bending radius fixed
- 6 x cable diameter
- Bending radius moved
- 6 x cable diameter
- Max operating temperature fixed
- +105°C
- Max operating temperature moved
- +105°C
- Testing voltage
- 2000V
- Max temperature at conductor
- +180°C
- Flame retardant
- IEC 60332-1
- E-number
- 0507662
- Dimension n x mm²
- 2x1,5
- Outer dimensions H x B mm
- 3,8 x 6,4
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 8.00
- Length
- 100 meters
- Packaging type
- Ring
- Number of cores
- 2.00
- Cross section mm²
- 1.50
