- Standard
- Cenelec HD383, 22-3 S3, IEC 245-3, VDE 0250
- Approvals
- 0,75-16,0mm² HAR approval, 25,0-150,0 mm² VDE
- Rated Voltage Uo/U
- 300/500V
- Conductor class
- Class 5 = fine stranded wires
- Conductor material
- Tinned Copper
- Core insulation
- Silicone
- Outer sheath
- Laquered glassfibre braid
- Sheat colour
- White
- Bending radius fixed
- 15 x cable diameter
- Min operating temperature fixed
- -60°C
- Max operating temperature fixed
- +180°C
- Testing voltage
- 2000V
- Insulation resistance
- >10 MOhm x km
- Max temperature at conductor
- +180°C
- Halogen-free / Smoke emission
- IEC 60 754-1 & IEC 60 754-2
- Flame retardant
- IEC 60332-1
- E-number
- 0386012
- Dimension n x mm²
- 1x0,75
- Outer diameter mm
- 2.90
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 1.60
- Number of cores
- 1.00
- Cross section mm²
- 0.75
- E-number
- 0386022
- Dimension n x mm²
- 1x1,0
- Outer diameter mm
- 3.20
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 1.80
- Number of cores
- 1.00
- Cross section mm²
- 1.00
- E-number
- 0386033
- Dimension n x mm²
- 1x1,5
- Outer diameter mm
- 3.50
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 2.50
- Number of cores
- 1.00
- Cross section mm²
- 1.50
- E-number
- 0386043
- Dimension n x mm²
- 1x2,5
- Outer diameter mm
- 4.20
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 3.80
- Number of cores
- 1.00
- Cross section mm²
- 2.50
- E-number
- 0386050
- Dimension n x mm²
- 1x4
- Outer diameter mm
- 4.70
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 5.40
- Number of cores
- 1.00
- Cross section mm²
- 4.00
- E-number
- 0386060
- Dimension n x mm²
- 1x6
- Outer diameter mm
- 5.30
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 7.60
- Number of cores
- 1.00
- Cross section mm²
- 6.00
- E-number
- 0386070
- Dimension n x mm²
- 1x10
- Outer diameter mm
- 7.20
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 13.10
- Number of cores
- 1.00
- Cross section mm²
- 10.00
- E-number
- 0386080
- Dimension n x mm²
- 1x16
- Outer diameter mm
- 8.40
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 21.20
- Number of cores
- 1.00
- Cross section mm²
- 16.00
- E-number
- 0386090
- Dimension n x mm²
- 1x25
- Outer diameter mm
- 10.40
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 31.70
- Number of cores
- 1.00
- Cross section mm²
- 25.00
- E-number
- 0386100
- Dimension n x mm²
- 1x35
- Outer diameter mm
- 11.70
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 42.70
- Number of cores
- 1.00
- Cross section mm²
- 35.00
- E-number
- 0386110
- Dimension n x mm²
- 1x50
- Outer diameter mm
- 13.80
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 60.40
- Number of cores
- 1.00
- Cross section mm²
- 50.00
- E-number
- N8301300
- Dimension n x mm²
- 1x70
- Outer diameter mm
- 15.90
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 81.50
- Number of cores
- 1.00
- Cross section mm²
- 70.00
- E-number
- N8301400
- Dimension n x mm²
- 1x95
- Outer diameter mm
- 18.70
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 109.70
- Number of cores
- 1.00
- Cross section mm²
- 95.00
- E-number
- N8301500
- Dimension n x mm²
- 1x120
- Outer diameter mm
- 20.40
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 136.20
- Number of cores
- 1.00
- Cross section mm²
- 120.00
- E-number
- N8301600
- Dimension n x mm²
- 1x150
- Outer diameter mm
- 23.40
- Protective conductor Yes/No
- Nej
- Weight kg/100m
- 171.50
- Number of cores
- 1.00
- Cross section mm²
- 150.00
